This section outlines the expressions in the built-in System object in Construct. Many are common mathematical operations, and they can be listed with descriptions in the Expressions dictionary, but they are included here for completeness.

This section does not list the operators or syntax that can be used in expressions - just the expressions specific to the System object. For more general information on how to use expressions in Construct, see Expressions.

Display

OriginalViewportWidth

OriginalViewportHeight

Get the original values of the Viewport size project property. The value of these expressions does not change even if actions like Set canvas size are used.

Layers

In expressions where a layer is required, either its name (as a string) or index (as a number, zero-based) can be entered.

CanvasToLayerX(layer, x, y)

CanvasToLayerY(layer, x, y)

Calculate the layout co-ordinates underneath a position in canvas CSS co-ordinates for a given layer.

LayerToCanvasX(layer, x, y)

LayerToCanvasY(layer, x, y)

Calculate the canvas CSS co-ordinates above a position in layout co-ordinates for a given layer.

LayerAngle(layer)

Get the angle, in degrees, of a layer.

LayerIndex(layer)

Get the zero-based index of a layer from its name.

LayerOpacity(layer)

Get the opacity (or semitransparency) of a layer, from 0 (transparent) to 100 (opaque).

LayerParallaxX(layer)

LayerParallaxY(layer)

Get the current parallax X and Y components of a layer.

LayerScale(layer)

Get the current scale of the layer, not including the overall layout scale.

LayerScaleRate(layer)

Get the current scale rate of the layer, which defines how quickly it scales (if at all).

LayerZElevation(layer)

Get the current elevation of the layer on the Z axis.

ViewportBottom(layer)

ViewportLeft(layer)

ViewportRight(layer)

ViewportTop(layer)

Return the viewport boundaries in layout co-ordinates of a given layer. Not all layers have the same viewport if they are parallaxed, scaled or rotated separately.

ViewportWidth(layer)

ViewportHeight(layer)

Return the size of the viewport in layout co-ordinates for a given layer.

Layout

CanvasSnapshot

Contains the resulting image from a Snapshot canvas action after On canvas snapshot has triggered. (Note this expression is not available immediately after the Snapshot canvas action - you can only use it after On canvas snapshot triggers.) The expression returns a data URI of the image file. This can be loaded in to a Sprite or Tiled Background object via Load image from URL, sent to a server or stored locally, or opened with the Browser object in a new tab to save to disk.

LayoutAngle

Get the angle, in degrees, of the current layout. This does not include the rotation of individual layers.

LayoutScale

Get the current scale of the entire layout set by the Set layout scale action. This does not include the scaling of individual layers.

LayoutWidth

LayoutHeight

Get the size of the current layout in pixels.

LayoutName

Get the name of the current layout.

ScrollX

ScrollY

Get the current position the view is centered on.

Math

These expressions are simply ordinary math functions like you find on calculators. However, note that all functions using an angle take it in degrees, not radians. Angles start with 0 degrees facing right and increment clockwise.

sin(x), cos(x), tan(x), asin(x), acos(x), atan(x) Trigonometric functions using angles in degrees.

abs(x) Absolute value of x e.g. abs(-5) = 5

angle(x1, y1, x2, y2) Calculate angle between two points

anglelerp(a, b, x) Linearly interpolate the angle a to b by x. Unlike the standard lerp, this takes in to account the cyclical nature of angles.

anglediff(a1, a2) Return the smallest difference between two angles

anglerotate(start, end, step) Rotate angle start towards end by the angle step, all in degrees. If start is less than step degrees away from end, it returns end.

ceil(x) Round up x e.g. ceil(5.1) = 6

cosp(a, b, x) Cosine interpolation of a to b by x. Calculates (a + b + (a - b) * cos(x * 180°)) / 2.

cubic(a, b, c, d, x) Cubic interpolation through a, b, c and d by x. Calculates lerp(qarp(a, b, c, x), qarp(b, c, d, x), x).

distance(x1, y1, x2, y2) Calculate distance between two points

exp(x) Calculate e^x

floor(x) Round down x e.g. floor(5.9) = 5

infinity A floating point number value representing infinity.

lerp(a, b, x) Linear interpolation of a to b by x. Calculates a + x * (b - a).

unlerp(a, b, y) Reverse linear interpolation: if lerp(a, b, x) = y, then unlerp(a, b, y) = x. Calculates (y - a) / (b - a).

ln(x) Log to base e of x.

log10(x) Log to base 10 of x.

max(a, b [, c...]), min(a, b [, c...]) Calculate maximum or minimum of the given numbers. Any number of parameters can be used as long as there are at least two.

pi The mathematical constant pi (3.14159...)

qarp(a, b, c, x) Quadratic interpolation through a, b and c by x. Calculates lerp(lerp(a, b, x), lerp(b, c, x), x).

round(x) Round x to the nearest whole number e.g. round(5.6) = 6

sign(x) Retrieve the sign of x: -1 for any negative number, 1 for any positive number, or 0 if x is zero.

sqrt(x) Calculate square root of x e.g. sqrt(25) = 5

getbit(x, n)

Get the nth bit of x represented as a 32-bit integer. For example getbit(7, 0) will get the least significant bit of the number 7 when represented as a 32-bit integer. Returns either 0 or 1.

setbit(x, n, b)

Set the nth bit of x represented as a 32-bit integer to b (either 0 or 1). The resulting 32-bit integer is returned.

togglebit(x, n)

Toggle the nth bit of x represented as a 32-bit integer. If that bit is 0, it is set to 1; if it is 1, it is set to 0. The resulting 32-bit integer is returned.

Memory management

ImageLoadingProgress

Return the current loading progress of any memory management Load actions that are currently busy, on a scale of 0-1.

Save & Load

SaveStateJSON

In On save complete or On load complete, returns a string of JSON data representing the savegame data. This can later be loaded using the Load from JSON action. For more information see How to make savegames.

System

CurrentEventNumber

CurrentEventSheetName

Return the number of the current event being run, and the name of the event sheet it belongs to. These are useful for testing purposes, such as logging the current event number to the browser console.

ImageMemoryUsage

Returns the estimated total memory usage, in megabytes, of all the currently-loaded images. Note image memory is sometimes also referred to as "VRAM", but this is not strictly correct since not all devices have video-specific memory. Also remember this expression does not include the memory use of sounds, code, or other non-image resources.

LoadingProgress

Return the current load progress on a loader layout. The progress is returned as a number from 0 to 1, e.g. 0.5 for half complete. For more information, see the tutorial how to make a custom loading screen.

LoopIndex

Get the index (number of repeats so far) in any currently running loop.

LoopIndex(name)

Get the index (number of repeats so far) of the loop with the given name. Useful for getting indices in nested loops.

ObjectCount

The total number of objects currently created.

ProjectName

Return the name of the project as it appears in Project Properties.

ProjectVersion

Return the version entered in to Project Properties. Note that this is always returned as a string, not a number.

Text

find(src, text)

findCase(src, text)

Find the first index within src that text occurs, else returns -1. find is case-insensitive, and findCase is case-sensitive.

left(text, count)

Return the first count characters of text.

len(text)

Return the number of characters in text.

lowercase(text)

Convert the given text to all lowercase.

mid(text, index, count)

Return the count characters starting from index in text.

newline

A string containing a line break. Use to insert line breaks in to strings, e.g. "Hello" & newline & "World"

RegexMatchAt(String, Regex, Flags, Index)

Process the regular expression Regex on String with Flags, and in the list of results, return the entry at Index.

RegexMatchCount(String, Regex, Flags)

Process the regular expression Regex on String with Flags, and return the number of entries in the list of results.

RegexReplace(String, Regex, Flags, Replace)

In String substitute matches for the regular expression Regex (with Flags) with the string Replace. The replacement string can contain the following special characters: $$ (inserts a $), $& (inserts the matched substring), $` (inserts the portion of the string that precedes the matched substring), or $' (inserts the portion of the string that follows the matched substring).

RegexSearch(String, Regex, Flags)

Return the index of the first character in String where a match for Regex with Flags could be found.

replace(src, find, rep)

Find all occurrences of find in src and replace them with rep.

right(text, count)

Return the last count characters of text.

tokenat(src, index, separator)

Return the Nth token from src, splitting the string by separator. For example, tokenat("apples|oranges|bananas", 1, "|") returns oranges.

tokencount(src, separator)

Count how many tokens occur in src using separator. For example, tokencount("apples|oranges|bananas", "|") returns 3.

trim(src)

Return src with all whitespace (spaces, tabs etc.) removed from the beginning and end of the string.

uppercase(text)

Convert the given text to all uppercase.

URLEncode(str)

URLDecode(str)

Convert to and from a string in a format suitable for including in a URL or POST data.

zeropad(number, digits)

Pad number out to a certain number of digits by adding zeroes in front of the number, then returning the result as a string. For example, zeropad(45, 5) returns the string "00045".

Time

CPUUtilisation

The percentage of the last second that was spent in logic, such as running events or processing behaviors. This is for performance measurements. Note on most devices the rendering happens on the separate GPU and so is not counted by this measurement; for that fps or GPUUtilisation is a better measure. Also note this measurement is based on timers so should be treated as an approximation, and it only measures time on the main thread.

The current frames per second (FPS) rate, which is how many times the screen is being drawn every second. Most computers run at 60 fps if they are fast enough.

GPUUtilisation

The percentage of the last second that was spent rendering the game. This represents how busy the graphics processing unit (GPU) is, which is useful for performance measurements. This measurement is based on timers so should be treated as an approximation. The GPU utilisation is only affected by the amount of rendering work to be done, such as the number of objects visible on-screen, and also increases if the window size is larger. Note this measurement is only available on certain systems, and also requires WebGL support. If it is not supported, it will return NaN (a special value representing Not A Number) to indicate there is no value available.

tickcount

The number of ticks that have run since the game started.

time

The number of seconds since the game started, taking in to account the time scale.

timescale

The current time scale.

unixtime

The current time represented in milliseconds since Jan 1, 1970. This is the standard way time is represented on many systems, and is commonly known as the UNIX time since it originated on UNIX systems.

wallclocktime

The number of seconds since the game started, not taking in to account the time scale (i.e. the real-world time).

Values

choose(a, b [, c...])

Choose one of the given parameters at random. E.g. choose(1, 3, 9, 20) randomly picks one of the four numbers and returns that. This also works with strings, e.g. choose("Hello", "Goodbye") returns either Hello or Goodbye. Any number of parameters can be used as long as there are at least two.

clamp(x, lower, upper)

Return lower if x is less than lower, upper if x is greater than upper, else return x.

float(x)

Convert the integer or text x to a float (fractional number). If x is text, non-numeric characters are allowed after the number, but not before. For example float("3.1xx") returns 3.1, but float("xx3.1") returns 0.

int(x)

Convert the float or text x to an integer (whole number). If x is text, non-numeric characters are allowed after the number, but not before. For example int("33xx") returns 33, but int("xx33") returns 0.

random(x)

Generate a random float from 0 to x, not including x. E.g. random(4) can generate 0, 2.5, 3.29293, but not 4. Use floor(random(4)) to generate just the whole numbers 0, 1, 2, 3.

random(a, b)

Generate a random float between a and b, including a but not including b.

rgbEx(r, g, b)

rgbEx255(r, g, b)

rgba(r, g, b, a)

rgba255(r, g, b, a)

Generate a single number containing a color with the given red, green, blue and optionally alpha components. rgbEx and rgba use components in the range 0-100, whereas rgbEx255 and rgba255 use components in the range 0-255. When an alpha is not provided, the resulting color is opaque. These are useful for conditions or actions taking a color parameter.

str(x)

Convert the integer or float x to a string. Generally this is not necessary since strings can be built using the & operator, e.g. "Your score is " & score
