Text script interface

The ITextInstance interface derives from IWorldInstance to add APIs specific to the Text plugin.

Text APIs

text
The string currently displayed by the Text object.
typewriterText(str, duration)
Set the text over time by starting with an empty string and gradually adding characters until the full text of str is written out, over a duration specified in seconds. Note modifying the text property while text is being written out will cancel the effect.
typewriterFinish()
If text is being written out with the typewriterText() method, force it to finish immediately.
fontColor
An array with 3 elements specifying the red, green and blue color of the text, with color values as floats in the 0-1 range.
fontFace
A string specifying the font used to display the text, e.g. "Arial".
isBold
isItalic
Booleans indicating whether the font face is displayed with bold or italic styles.
sizePt
The size of the displayed text, in points (pt).
lineHeight
The extra space in pixels to add vertically between lines. 0 is the default size, negative values make lines closer together, and positive values space lines out further apart.
horizontalAlign
A string specifying the horizontal alignment of the text within the object bounding box, which must be one of "left", "center" or "right".
verticalAlign
A string specifying the vertical alignment of the text within the object bounding box, which must be one of "top", "center" or "bottom".
readAloud
A boolean indicating whether the contents of the text object will be read aloud by screen reader software. See the Read aloud property of the Text object for more details.
textDirection
Set or get a string of either "ltr" (left-to-right) or "rtl" (right-to-left) specifying the direction of the text flow. See the Text direction property of the Text object for more details.
wordWrapMode
A string specifying the way to wrap text when it reaches the end of a line. This can be either "word" to wrap entire space-separated words, or "character" to wrap at any character.
textWidth
textHeight
getTextSize()
Read-only values indicating the size of the actual text content within the text object's rectangle. The method allows getting both values at the same time.
hasTagAtPosition(tag, x, y)
Return a boolean indicating if there is text with a specific tag at the given position (case insensitive). For example if the text has the BBcode Hello [tag=mytag]world[/tag], then testing if the tag "mytag" is at a given position return true if that position is over just the part of the text that says "world", else false.
getTagAtPosition(x, y)
Look up the tag for a part of the text at a given position and return the tag if any, else return an empty string if no tag is specified. For example if the text has the BBcode Hello [tag=mytag]world[/tag], then the tag at a position over the word "world" is "mytag", and the tag at a position over the word "Hello" is "".
getTagCount(tag)
getTagPositionAndSize(tag, index)
Get the number of fragments, and the size and position of each fragment by its zero-based index, for a given tag. Note that a single tag may be broken in to multiple fragments - see the section Tagged range fragmentation in the Text object manual entry for more details. The getTagPositionAndSize() method returns the position and size as an object with the properties {x, y, width, height}.
changeIconSet(objectClass)
Changes the Icon set property, replacing the Sprite used for BBcode icons to the one specified by the given IObjectClass (which must be from a Sprite object). This can be used to change the set of icons displayed by the Text object. Note if the new Sprite object does not have the same number of animation frames, or the same animation frame tags, then some icons may disappear.
async getAsHtmlString()
Converts the contents of the Text object, including any icons, in to a string of HTML. This process is asynchronous so the method must be awaited. It resolves with a string of HTML code. The result is cached (and updates the AsHTML expression) so repeat calls will resolve with the same HTML string, until the Text object contents is modified, after which the next call will regenerate the HTML string again.
