Rotate behavior

The Rotate behavior makes an object spin.

Scripting

When using JavaScript or TypeScript coding, the features of this behavior can be accessed via the IRotateBehaviorInstance script interface.

Rotate properties

Speed
The rate of rotation, in degrees per second. Use a positive value for clockwise rotation and negative for anticlockwise rotation.
Acceleration
The rate the rotation speed changes, in degrees per second per second. Use a positive value to accelerate clockwise and a negative to accelerate anticlockwise.
Enabled
Whether the behavior is initially enabled or disabled. If disabled, it can be enabled at runtime using the Set enabled action.
Preview Paid plans only
Enable to run a preview of the behavior directly in the Layout View.

Rotate conditions

Is enabled
Test if the behavior is currently enabled. When disabled it will have no effect on the object.

Rotate actions

Set acceleration
Set speed
Set the corresponding properties. See Rotate properties.
Set enabled
Enable or disable the movement. If disabled, the behavior will stop rotating the object.

Rotate expressions

Acceleration
Return the corresponding Acceleration property.
Speed
Return the current rotating speed, in degrees per second. A positive value indicates clockwise rotation and a negative value indicates anticlockwise rotation.
Construct 3 Manual 2024-02-16
