Platform behavior script interface

Ashley's avatar
Medal
Construct Team Founder
Published 14 Oct, 2019
469 words
~2-3 mins

The IPlatformBehaviorInstance interface derives from IBehaviorInstance to add APIs specific to the Platform behavior.

Platform behavior APIs

fallThrough()

If the player is currently standing on a jump-thru platform, this method will make them fall through it.

resetDoubleJump(allow)

Change whether a double-jump is allowed during the current jump. If false passed, a double-jump will no longer be allowed in the current jump, even if it is the first jump. If true passed a double-jump will be allowed again, even if a double-jump was already made in the current jump.

simulateControl(control)

Simulate one of the movement controls being held down. Useful when isDefaultControls is disabled. The control is provided as a string and must be one of "left", "right", "jump".

speed

Get the current speed in pixels per second (read-only).

maxSpeed

Set or get the maximum speed in pixels per second.

acceleration

deceleration

Set or get the acceleration/deceleration of the movement in pixels per second per second.

vectorX

vectorY

Set or get the X and Y components of the movement in pixels per second.

jumpStrength

Set or get the initial vertical speed of a jump in pixels per second when the jump key is pressed.

maxFallSpeed

Set or get the maximum speed in pixels per second the object can accelerate to when in free-fall.

gravity

Set or get the acceleration caused by gravity, in pixels per second per second, at the angle given by gravityAngle.

gravityAngle

Set or get the angle that gravity accelerates the object, in radians. By default this points down.

isDoubleJumpEnabled

A boolean indicating if the player may make one extra mid-air jump before landing on the ground.

jumpSustain

Set or get the maximum time in seconds that the jump strength is sustained at while the jump control is being held before the effect of gravity takes over.

isOnFloor

A read-only boolean indicating if the object is currently standing on a solid or jump-thru.

isByWall(side)

Test if a solid blocking horizontal movement is immediately to the object's left or right, returning a boolean indicating if a wall was found. Jump-thrus do not count as walls. Pass either "left" or "right" as the side.

isJumping

A read-only boolean indicating if the object is currently moving upwards.

isFalling

A read-only boolean indicating if the object is currently in free-fall.

ceilingCollisionMode

A string of either "stop" (the default) or "preserve-momentum" (keep the vertical speed) indicating how to handle ceiling collisions.

isDefaultControls

A boolean indicating if the default controls (using the arrow keys) are enabled.

isIgnoringInput

A boolean indicating if input is currently being ignored. If input is ignored, pressing any of the control keys has no effect. However, unlike disabling the behavior, the object can continue to move.

isEnabled

A boolean indicating if the behavior is enabled. If disabled, the behavior no longer has any effect on the object.
