Pin behavior

The Pin behavior positions an object at a relative distance and angle to another object, giving the impression it has been "pinned" to the object. It can also pin other properties like the size. For examples, search for Pin in the Start Page.

Simply adding the Pin behavior to an object does not do anything. You must use the Pin action to pin the object to another object.

Pin properties

Destroy with pinned object
Enable to automatically destroy this object if the object it is currently pinned to is destroyed.

Pin conditions

Is pinned
True if the object is currently pinned to another object.
Will destroy with pinned object
True if the Destroy with pinned object option is enabled.

Pin actions

Pin at distance
Pin the object to another object, restricting the distance between the objects. The two possible modes are:

  • Rope style (maximum distance): the object is kept at a maximum distance from the other object, but is allowed to move closer.

  • Bar style (fixed distance): the object is kept at a fixed distance from the other object, and will be moved away if the object object gets closer.


Note the distance between the objects at the time this action runs is used as the distance limit between the objects. The distance limit can be changed with the Set pin distance action.
Pin to object
Pin to image point
Pin one or more properties of the object to another object. The relative difference between the objects at the moment the Pin action is used is remembered. A series of checkboxes allows selection of which properties are to be kept pinned. For example ticking only the X and Y options will keep the object at the same relative position, but not change its angle. The Width and Height options have two possible modes if enabled: Absolute, which will apply the same size change value (e.g. if the pinned object gets 10 pixels wider, this object will also get 10 pixels wider); and Scale, which will apply the same relative size change (e.g. if the pinned object gets 50% wider, this object will also get 50% wider, relative to its starting size).
Pin to image point works the same as Pin to object, except instead of enabling the X and Y properties, it specifies an image point on the pinned object (by its name or number). The object will be positioned exactly at that image point while pinned, rather than keeping a relative difference.
Set destroy with pinned object
Set the current state of the Destroy with pinned object property.
Set pin distance
When using Pin at distance, set the distance limit in pixels that is used.
Unpin
Unpin the object, so it is no longer being positioned by the Pin behavior.

Pin expressions

PinnedUID
Get the UID of the object currently pinned to, or -1 if not pinned. For more information on UIDs, see instances.
