Timeline track folder

Ashley's avatar
Medal
Construct Team Founder
Published 10 May, 2019
230 words
~1-2 mins

In the Timeline Bar, track folders are represented as a row with an icon of a folder.

These are used to organize elements in a timeline, and don't have any impact in the playback. A track folder can have nested tracks as well as other track folders. They can be moved to and from track folders or the root of the timeline by dragging and dropping.

It is worth noting that the only specific property of a track folder is the Name. Every other property in it doesn't have a direct impact on the folder itself and exists only as a convenience to make modifications in all of the items within it.

Adding Track Folders

Track folders can be added to the root of a timeline by doing any of the following:

  • Right-clicking any section of the bar which doesn't correspond to any other element of a timeline and selecting Add subfolder.
  • Using the split menu of the Timeline Bar Add toolbar button, and selecting Add subfolder.

A track folder can be created as sub folders by right-clicking another track folder.

Track Folder Properties

Name

The name of the track folder.

Animation mode

Result mode

Ease

Path mode

Visible

Enabled

Locked

See the section on common timeline element properties in Timelines. Changing these at the track folder level will apply the change to every sub-element.
