The set of actions, conditions and expressions which are available in your addon is defined in aces.json. The term "ACE" is used to refer to an action, condition or expression in general. ACEs are grouped by category. The overall structure of the file format is as follows.

{
	"category1": {
		"conditions": [
			condition1,
			condition2,
			...
		],
		"actions": [
			action1,
			action2,
			...
		],
		"expressions": [
			expression1,
			expression2,
			...
		]
	},
	"category2": {
		"conditions": [
			...
		],
		"actions": [
			...
		],
		"expressions": [
			...
		]
	}
}

Note that Construct 2 uses numbers for IDs, whereas Construct 3 uses strings. These strings are then also used to identify related language strings in the language file.

Categories

Each category key is the category ID. This is not displayed in the editor; the string to display is looked up in the language file.

For behaviors only, a default category of an empty string may be used. This category will use the behavior name. Other categories may still be used, in which case Construct 3 will append the category name after the behavior name, e.g. "MyBehaviorName: My category".

Common properties of ACE definitions

Each entry in the "conditions", "actions" and "expressions" arrays is a JSON object which defines a single condition, action or expression. An example minimal condition definition for the System Every Tick condition is shown below.

{
	"id": "every-tick",
	"scriptName": "EveryTick"
}

The id and scriptName are the only required properties for conditions and actions. Expressions require id, expressionName and returnType. All other properties are optional.

The definitions for conditions, actions and expressions all share a few common properties. These are detailed below. Then the properties specific to each kind is documented after that.

id

A string specifying a unique ID for the ACE. This is used in the language file. By convention this is lowercase with dashes for separators, e.g. "my-condition".

c2id

If you are porting a Construct 2 addon to Construct 3, put the corresponding numerical ID that the Construct 2 addon used here. This allows Construct 3 to import Construct 2 projects using your addon.

scriptName / expressionName

The name of the function in the runtime script for this ACE. Note for expressions, use expressionName instead, which also defines the name typed by the user in expressions.

isDeprecated

Set to true to deprecate the ACE. This hides it in the editor, but allows existing projects to continue using it.

highlight

Set to true to highlight the ACE in the condition/action/expression picker dialogs. This should only be used for the most regularly used ACEs, to help users pick them out from the list easily.

params

An array of parameter definitions. See the section below on parameters. This can be omitted if the ACE does not use any parameters.

Condition definitions

Condition definitions can also use the following properties.

isTrigger

Specifies a trigger condition. This appears with an arrow in the event sheet. Instead of being evaluated every tick, triggers only run when they are explicity triggered by a runtime call.

isFakeTrigger

Specifies a fake trigger. This appears identical to a trigger in the event sheet, but is actually evaluated every tick. This is useful for conditions which are true for a single tick, such as for APIs which must poll a value every tick.

isStatic

Normally, the condition runtime method is executed once per picked instance. If the condition is marked static, the runtime method is executed once only, on the object type class. This means the runtime method must also implement the instance picking entirely itself, including respecting negation and OR blocks.

isLooping

Display an icon in the event sheet to indicate the condition loops. This should only be used with conditions which implement re-triggering.

isInvertible

Allow the condition to be inverted in the event sheet. Set to false to disable invert.

isCompatibleWithTriggers

Allow the condition to be used in the same branch as a trigger. Set to false if the condition does not make sense when used in a trigger, such as the Trigger once condition.

Action definitions

Action definitions can also use the following properties.

isAsync

Set to true to mark the action as asynchronous. Make the action method an async function, and the system Wait for previous actions to complete action will be able to wait for the action as well.

Expression definitions

Expressions work slightly differently to conditions and actions: they must specify a returnType, and instead of using a scriptName they specify an expressionName which doubles as both what is typed for the expression as well as the runtime script function name.

returnType

One of "number", "string", "any". The runtime function must return the corresponding type, and "any" must still return either a number or a string.

isVariadicParameters

If true, Construct 3 will allow the user to enter any number of parameters beyond those defined. In other words the parameters (if any) listed in "params" are required, but this flag enables adding further "any" type parameters beyond the end.

Parameter definitions

ACEs can all define which parameters they use with the "params" property. This property should be set to an array of parameter definition objects. Below shows an example for the System Compare two values condition.

{
	"id": "compare-two-values",
	"scriptName": "Compare",
	"params": [
		{	"id": "first-value",	"type": "any" },
		{	"id": "comparison",		"type": "cmp" },
		{	"id": "second-value",	"type": "any" }
	]
}

Note that expressions can only use "number", "string" or "any" parameter types.

id

A string with a unique identifier for this parameter. This is used to refer to the parameter in the language file.

c2id

In some circumstances, it is necessary to specify which Construct 2 parameter ID a parameter corresponds to. However normally it can be inferred by the parameter index.

type

The parameter type. Expressions can only use "number", "string" or "any". However conditions and actions have the following options available:

  • "number" — a number parameter
  • "string" — a string parameter
  • "any" — either a number or a string
  • "boolean" — a boolean parameter, displayed as a checkbox
  • "combo" — a dropdown list. Items must be specified with the "items" property.
  • "cmp" — a dropdown list with comparison options like "equal to", "less than" etc.
  • "object" — an object picker. The types of plugin to show can be filtered using an optional "allowedPluginIds" property.
  • "objectname" — a string parameter which is interpreted as an object name
  • "layer" — a string parameter which is interpreted as a layer name
  • "layout" — a dropdown list with every layout in the project
  • "keyb" — a keyboard key picker
  • "instancevar" — a dropdown list with the non-boolean instance variables the object has
  • "instancevarbool" — a dropdown list with the boolean instance variables the object has
  • "eventvar" — a dropdown list with non-boolean event variables in scope
  • "eventvarbool" — a dropdown list with boolean event variables in scope
  • "animation" — a string parameter which is interpreted as an animation name in the object
  • "objinstancevar" — a dropdown list with non-boolean instance variables available in a prior "object" parameter. Only valid when preceded by an "object" parameter.

initialValue

A string which is used as the initial expression for expression-based parameters. Note this is still a string for "number" type parameters. It can contain any valid expression for the parameter, such as "1 + 1". For "boolean" parameters, use a string of either "true" or "false". For "combo" parameters, this is the initial item ID.

items

Only valid with the "combo" type. Set to an array of item IDs available in the dropdown list. The actual displayed text for the items is defined in the language file.

allowedPluginIds

Optional and only valid with the "object" type. Set to an array of plugin IDs allowed to be shown by the object picker. For example, use ["Sprite"] to only allow the object parameter to select a Sprite.

Language strings

The aces.json file does not include any strings displayed in the editor UI. These are all kept in a separate language file to facilitate translation. Therefore to finish adding ACEs, the relevant UI strings like the list name and description must be added to the language file. See The language file for more information.
