Hello
Ashley!
I’ve been investigating how Construct 3 assembles sprite sheets during export, especially regarding memory optimization and the organization of multiple objects and animations. I carefully read the manual and conducted several practical tests, and I’d like to confirm if my interpretation is correct — particularly on a point that I couldn’t find mentioned in the manual.
What is already documented (and confirmed through testing):
Sprite sheets are always assembled in sizes that are powers of two.
For example, if an object has a 32x32 texture, it will be placed in a 32x32 sprite sheet. If there are more objects or more frames, the size can increase to something like 64x128.
There is padding between images.
Even images that are exactly the right size (like 32x32) can end up taking up more space due to this automatic padding — the manual recommends that images be a few pixels below a power of two (like 508px instead of 512px) for better space usage.
Sizes slightly above powers of two waste memory.
For example, a 530px x 530px image fits poorly in a 2048x2048 sprite sheet compared to a 500px x 500px image — this point is well explained in the manual.
Additional observations based on testing:
Sprite size influences the sprite sheet layout.
If I create two 32x32 objects, the resulting sprite sheet that contains them becomes 64x128, presumably due to padding.
➤ However, if I create the same objects at 30x30, the resulting sprite sheet is 32x64 — showing that slightly smaller objects effectively save space, as the manual suggests.
NEW DISCOVERY
(main point of my question):
If two different objects each have fewer than 8 frames, they are typically grouped together in the same sprite sheet.
➤ However, if a single object has 8 or more frames, it gets its own sprite sheet, even if its frames are small (like 32x32). This consistently occurred in my tests, including when changing resolutions and the number of objects in the layout.
My questions are:
Is this behavior of isolating objects with 8 or more frames in their own sprite sheets intentional?
Is there a specific technical reason for this 8-frame limit? (e.g., limitations of the texture packer, loading optimizations, etc.)
Is it possible to control or influence this behavior in any way to better group similar objects together?
I find this behavior quite interesting and think it could help many developers optimize their projects better — but I wanted to confirm if my analysis is correct
I appreciate any clarification you can provide!
