IPluginInfo interface

IPluginInfo defines the configuration for a plugin. It is typically accessed in the plugin constructor via this._info.

Methods

SetName(name)

Set the name of the addon. Typically this is read from the language file.

SetDescription(description)

Set the description of the addon. Typically this is read from the language file.

SetVersion(version)

Set the version string of the addon, in A.B.C.D form. Typically this is set to the PLUGIN_VERSION constant.

SetCategory(category)

Set the category of the addon. Typically this is set to the PLUGIN_CATEGORY constant. It must be one of "data-and-storage", "form-controls", "general", "input", "media", "monetisation", "platform-specific", "web", "other".

SetAuthor(author)

Set a string identifying the author of the addon.

SetHelpUrl(url)

Set a string specifying a URL where the user can view help and documentation resources for the addon. The website should be hosted with HTTPS.

SetPluginType(type)

Set the plugin type. This can be "object" or "world". The world typeh represents a plugin that appears in the Layout View, whereas the object type represents a hidden plugin, similar to the Audio plugin (a single-global type) or Dictionary. World type plugins must derive from SDK.IWorldInstanceBase instead of SDK.IInstanceBase and implement a Draw() method.

SetIcon(url, type)

Set the addon icon URL and type. By default the URL is "icon.svg" and the type is "image/svg+xml". It is recommended to leave this at the default and use an SVG icon, since it will scale well to any display size or density. However you can change your addon to load a PNG icon with SetIcon("icon.png", "image/png").

SetIsResizable(isResizable)

For "world" type plugins only. Pass true to enable resizing instances in the Layout View.

SetIsRotatable(isRotatable)

For "world" type plugins only. Pass true to enable the Angle property and rotating instances in the Layout View.

SetIs3D(is3d)

For "world" type plugins only. Pass true to specify that this plugin renders in 3D. This will cause the presence of the plugin in a project to enable 3D rendering when the project Rendering mode property is set to Auto (which is the default setting).

SetHasImage(hasImage)

For "world" type plugins only. Pass true to add a single editable image, such as used by the Tiled Background plugin.

SetDefaultImageURL(url)

For plugins that use a single editable image only. Set the URL to an image file in your addon to use as the default image when the object is added to a project, e.g. "default.png".

SetIsTiled(isTiled)

For "world" type plugins only. Pass true to indicate that the image is intended to be tiled. This adjusts the texture wrapping mode when Construct creates a texture for its image.

SetIsDeprecated(isDeprecated)

Set a boolean of whether the addon is deprecated or not. If you wish to replace your addon with another one, the old one can be deprecated with SetIsDeprecated(true). This makes it invisible in the editor so it cannot be used in new projects; however old projects with the addon already added can continue to load and work as they did before. This discourages use of the deprecated addon without breaking existing projects that use it.

SetIsSingleGlobal(isSingleGlobal)

Pass true to set the plugin to be a single-global type. The plugin type must be "object". Single-global plugins can only be added once to a project, and they then have a single permanent global instance available throughout the project. This is the mode that plugins like Touch and Audio use.

SetSupportsZElevation(supportsZElevation)

Pass true to allow using Z elevation with this plugin. The plugin type must be "world". By default the renderer applies the Z elevation before calling the Draw() method on an instance, which in many cases is sufficient to handle rendering Z elevation correctly, but be sure to take in to account Z elevation in the drawing method if it does more complex rendering.

SetSupportsColor(supportsColor)

Pass true to allow using the built-in color property to tint the object appearance. The plugin type must be "world". By default the renderer sets the color before calling the Draw() method on an instance, which in many cases is sufficient to handle rendering with the applied color, but be sure to take in to account the instance color in the drawing method if it does more complex rendering.

SetSupportsEffects(supportsEffects)

Pass true to allow using effects, including the Blend mode property, with this plugin. The plugin type must be "world". If the plugin does not simply draw a texture the size of the object (as Sprite does), you should also call SetMustPreDraw(true).

SetMustPreDraw(mustPreDraw)

Pass true to disable an optimisation in the effects engine for objects that simply draw a texture the size of the object (e.g. Sprite). This is necessary for effects to render correctly if the plugin draws anything other than the equivalent the Sprite plugin would.

SetCanBeBundled(canBeBundled)

Pass false to prevent the addon from being bundled via the Bundle addons project property. By default all addons may be bundled with a project, and it is recommended to leave this enabled for best user convenience. However if you publish a commercial addon and want to prevent it being distributed by project-bundling, you may wish to disable this.

AddCommonPositionACEs()

AddCommonSceneGraphACEs()

AddCommonSizeACEs()

AddCommonAngleACEs()

AddCommonAppearanceACEs()

AddCommonZOrderACEs()

Add common built-in sets of actions, conditions and expressions (ACEs) to the plugin relating to various built-in features.

SetProperties(propertiesArray)

Set the available addon properties by passing an array of PluginProperty. See Configuring Plugins for more information.

AddCordovaPluginReference(opts)

Add a dependency on a Cordova plugin, that will be included when using the Cordova exporter. For more information see Specifying dependencies.

AddCordovaResourceFile(opts)

Add a resource file to be included with Cordova exports. For more information see Specifying dependencies.

AddFileDependency(opts)

Add a dependency on another file included in the addon. For more information see Specifying dependencies.

AddRemoteScriptDependency(url) Not recommended

Add a script dependency to a remote URL (on a different origin). For more information see Specifying dependencies.

SetGooglePlayServicesEnabled(enabled)

Pass true to enable Google Play Services in Cordova Android exports. <preference name="GradlePluginGoogleServicesEnabled" value="true" /> will be added in config.xml.

SetDOMSideScripts(arr)

Specify an array of script paths to load in the main document context rather than the runtime context. For more information see the section DOM calls in the C3 runtime in Runtime scripts.

SetScriptInterfaceNames(opts)

Use this method to tell Construct the names of your script interface classes. This is necessary to generate the correct TypeScript definition files. opts is an object which allows specifying the names for the instance, objectType and plugin interface names as necessary, e.g.:

this._info.SetScriptInterfaceNames({

	instance: "ISpriteInstance"

});

SetTypeScriptDefinitionFiles(arr)

Specify an array of TypeScript definition files (.d.ts) your addon provides. This should be used to provide full TypeScript definitions of any script interfaces your addon provides, which is necessary for projects using TypeScript with your addon. Example:

this._info.SetTypeScriptDefinitionFiles(["c3runtime/ISpriteInstance.d.ts"]);
